Due to the size of this mower, liftgate residential delivery may be limited.
Z560X
The Husqvarna Z500 series zero turn mower represents the latest design focused on productivity, durability and cut quality. Providing extreme comfort, high ground speeds and superior traction adds up to exceptional mowing efficiency. Industrial strength throughout the entire design assures of a long & durable service life while careful design consideration provides unprecedented ease in serviceability.
Capacity
Z560X Professional Zero Turn Mower
SKU: 967 66 97‑01
Cutting width
60 in
Speed forward min
0 mph
Speed forward max
12 mph
Emission
Exhaust emissions (CO₂ EU V)2
809 g/kWh
Cutting deck
Cutting Methods (filter)
Side discharge
Cutting methods
Collect/Mulch/Side discharge
Deck thickness
7 gauge
Deck Wash Port
No
Greasable mandrels
Yes
Nose roller
No
Powder-coated cutting deck
Yes
Spindle/mandrel type
Cast iron
Deck lifting system
Manual, foot activated
Cutting height steps
16
Cutting deck type
7-gauge fabricated
Anti-scalp wheels
6
Blade engagement
Electric clutch
Blades
3 pcs
Cutting deck material
Steel
Cutting height, min (approximate)
1 in
Cutting height, max (approximate)
5 in
Dimensions
Weight
1,309 lbs
Base machine, height (ROPS down)
46 in
Base machine, height (ROPS up)
73 in
Base machine, height
46 in
Base machine, length
81 in
Base machine, width (chute down)
74 in
Base machine, width (chute up)
63.75 in
Drive system
Transmission manufacturer
Hydro-Gear
Transmission type
Hydrostatic
Engine
Engine name
FX Series V-Twin
Engine Power (As rated by the engine manufacturer)1
